Filtered Element Collector Benchmark

Back to the Revit API, I recently reiterated the differences between slow, slower still and faster filtering ↗.

In the end, the only way to tell whether your filter is performing well or not is to implement some benchmarking ↗ for it.

Jai Hari Hara Sudhan very commendably did so, documenting his progress and sharing his results in a series of ↗ comments on ↗ that post ↗ and in his API speed test screencast ↗ demonstrating the benchmark running live.

Here is a summary of our discussion and his final benchmarking code:

Question: The above content is very useful.

I am using three methods to filter and select the element:

  1. Using FilterRule method (filters in floor by floor / level)
  2. Using Factory Method (filters in the projects)
  3. Selection with interface (element by element)

Question 1. Which one is the best in performance (quick)? FilterRule or Factory method?

Question 2. In the FamilySelectionFilter method, is there any better or more performant method to select the elements?

Answer: Nobody can tell you beforehand how these different approaches will perform in your specific context.

I therefore suggest that you benchmark them yourself and let us know the result.

The Building Coder topic groups ↗ lists several benchmarking examples that you can look at to see how.

Response: I implemented a benchmark.

It is impossible to determine exact constant performance (time), because the results differ from run to run.

Please refer to my API speed test screencast ↗.

Finally, I rank the different approaches as follows:

  1. Factory method (average time = 766.1 microseconds)
    – 100%
  2. FilterRule method (average time = 889.0 microseconds)
    – 116% slower than Factory
  3. Linq2 method (average time = 983.5 microseconds)
    – 128% slower than Factory
  4. Linq1 method (average time = 1173.3 microseconds)
    – 153% slower than Factory

The code as follows:

[Transaction( TransactionMode.Manual )]
public class Elec_test : IExternalCommand
{
  public Result Execute(
    ExternalCommandData commandData,
    ref string message,
    ElementSet elements )
  {
    UIApplication uiapp = commandData.Application;
    UIDocument uidoc = uiapp.ActiveUIDocument;
    Application app = uiapp.Application;
    Document doc = uidoc.Document;
    Selection sel = uidoc.Selection;

    TaskDialog.Show( "BuilDTecH Architects",
      "BuilDTecH Architects by Sudhan" );

    InputData InputData = new InputData();
    InputData.ShowDialog();
    IList<object> data = InputData.Data;

    /////////////////////////////// Input Values
    double LeftOffset = Convert.ToDouble( data[1] ),
    RightOffset = Convert.ToDouble( data[2] ),
    TopOffset = Convert.ToDouble( data[3] ),
    BottomOffset = Convert.ToDouble( data[4] ),
    NearClipOffset = -Convert.ToDouble( data[5] ),
    FarClipOffset = Convert.ToDouble( data[6] );
    string Section_Name = "Electrical GangBox",
    ElectricalEquipment = "Modular Gang Box";
    //Input /////////////////////////////// Input Values

    if( data[0].Equals( InputData.Option.ByFloor ) )
    {
      Timer floortimeLinq1 = new Timer();
      floortimeLinq1.Start();
      IEnumerable<Element> elems = Linq1( doc,
        BuiltInCategory.OST_ElectricalEquipment,
        ElectricalEquipment );

      floortimeLinq1.Stop();
      TaskDialog.Show( "time", "LINQ1 Method Time = "
        + floortimeLinq1.Duration.ToString()
        + " No. of Elements = " + elems.Count().ToString() );

      elems = null;
      Timer floortimeLinq2 = new Timer();
      floortimeLinq2.Start();
      elems = Linq2( doc,
        BuiltInCategory.OST_ElectricalEquipment,
        ElectricalEquipment );

      floortimeLinq2.Stop();
      TaskDialog.Show( "time", "LINQ2 Method Time = "
        + floortimeLinq2.Duration.ToString()
        + " No. of Elements = " + elems.Count().ToString() );

      elems = null;

      Timer floortimeFilterRule = new Timer();
      floortimeFilterRule.Start();
      elems = FilterRule( doc, // uidoc.ActiveView.Id,
        BuiltInCategory.OST_ElectricalEquipment,
        ElectricalEquipment );

      floortimeFilterRule.Stop();
      TaskDialog.Show( "time", "Filter Rule Method Time = "
        + floortimeFilterRule.Duration.ToString()
        + " No. of Elements = " + elems.Count().ToString() );
      elems = null;

      Timer floortimeFactoryRule = new Timer();
      floortimeFactoryRule.Start();

      elems = Factory( doc,
        BuiltInCategory.OST_ElectricalEquipment,
        ElectricalEquipment );

      floortimeFactoryRule.Stop();

      TaskDialog.Show( "time", " Factory Rule Method Time = "
        + floortimeFactoryRule.Duration.ToString()
        + " No. of Elements = " + elems.Count().ToString() );
    }
    else if( data[0].Equals( InputData.Option.BySingle ) )
    {
      TaskDialog td = new TaskDialog( "Element By Element" );
      td.Title = "Want to Continue";
      td.MainInstruction = "Do you want to create a new section";
      td.CommonButtons = TaskDialogCommonButtons.Yes
        | TaskDialogCommonButtons.No;
      td.DefaultButton = TaskDialogResult.Yes;
      bool next = true;
      while( next )
      {
        ISelectionFilter selFilter
          = new FamilySelectionFilter( doc,
            BuiltInCategory.OST_ElectricalEquipment,
            ElectricalEquipment );
        Reference refe = sel.PickObject(
          ObjectType.Element, selFilter, "Select Object" );
        Element ele = doc.GetElement( refe );
        Draw_Section.Draw( doc, ele, Section_Name,
          LeftOffset, RightOffset, TopOffset, BottomOffset,
          NearClipOffset, FarClipOffset );

        TaskDialogResult tdRes = td.Show();
        if( tdRes == TaskDialogResult.No )
        { next = false; }
      }
    }
    else if( data[0].Equals( InputData.Option.ByProject ) )
    {
      Timer floortimeFactoryRule = new Timer();
      floortimeFactoryRule.Start();
      IEnumerable<Element> elems = Factory( doc,
        BuiltInCategory.OST_ElectricalEquipment,
        ElectricalEquipment );
      floortimeFactoryRule.Stop();
      TaskDialog.Show( "time", " Factory Rule Method Time = "
        + floortimeFactoryRule.Duration.ToString()
        + " No. of Elements = " + elems.Count().ToString() );
      foreach( Element ele in elems )
      {
        Draw_Section.Draw( doc, ele, Section_Name,
          LeftOffset, RightOffset, TopOffset, BottomOffset,
          NearClipOffset, FarClipOffset );
      }
    }
    return Result.Succeeded;
  }
  public class FamilySelectionFilter : ISelectionFilter
  {
    Document Doc;
    string FmlyName = "";
    int BultCatId;
    public FamilySelectionFilter(
      Document doc,
      BuiltInCategory BuiltInCat,
      string familyTypeName )
    {
      Doc = doc;
      FmlyName = familyTypeName;
      BultCatId = (int) BuiltInCat;
    }

    public bool AllowElement( Element elem )
    {
      return elem.Category.Id.IntegerValue == BultCatId;
    }

    public bool AllowReference( Reference refer, XYZ point )
    {
      Element e = Doc.GetElement( refer );
      return e.get_Parameter( BuiltInParameter.ELEM_FAMILY_PARAM )
        .AsValueString().Equals( FmlyName );
    }
  }

  #region Retrieve named family type using either LINQ or a parameter filter
  static IEnumerable<Element> Linq1(
  Document doc,
  BuiltInCategory BultCat,
  string familyTypeName )
  {

    return new FilteredElementCollector( doc ).OfCategory( BultCat ).OfClass( typeof( FamilyInstance ) )
    .Cast<FamilyInstance>()
    .Where( x => x.Symbol.Family.Name.Equals( familyTypeName ) );
  }

  static IEnumerable<Element> Linq2(
  Document doc,
  BuiltInCategory BultCat,
  string familyTypeName )
  {
    return new FilteredElementCollector( doc ).OfClass( typeof( FamilyInstance ) ).Cast<FamilyInstance>()
    .Where( x => x.get_Parameter( BuiltInParameter.ELEM_FAMILY_PARAM )
     .AsValueString() == familyTypeName );
  }
  static IEnumerable<Element> FilterRule(
  Document doc,
  // ElementId ActiveViewId,
  BuiltInCategory BultCat,
  string familyTypeName )
  {
    return new FilteredElementCollector( doc )//,ActiveViewId)
    .OfCategory( BultCat )
    .OfClass( typeof( FamilyInstance ) )
    .WherePasses(
    new ElementParameterFilter(
    new FilterStringRule(
    new ParameterValueProvider(
    new ElementId( BuiltInParameter.ELEM_FAMILY_PARAM ) ),
    new FilterStringEquals(), familyTypeName, true ) ) );
  }
  static IEnumerable<Element> Factory(
  Document doc,
  BuiltInCategory BultCat,
  string familyTypeName )
  {
    return new FilteredElementCollector( doc )
    .OfCategory( BultCat )
    .OfClass( typeof( FamilyInstance ) )
    .WherePasses(
    new ElementParameterFilter(
    ParameterFilterRuleFactory.CreateEqualsRule(
    new ElementId( BuiltInParameter.ELEM_FAMILY_PARAM ), familyTypeName, true ) ) );
  }
  #endregion // Retrieve named family symbols using either LINQ or a parameter filter

  #region Timer
  public class Timer
  {
    [DllImport( "Kernel32.dll" )]
    private static extern bool QueryPerformanceCounter(
    out long lpPerformanceCount );

    [DllImport( "Kernel32.dll" )]
    private static extern bool QueryPerformanceFrequency(
    out long lpFrequency );

    private long startTime, stopTime;
    private long freq;

    /// <summary>
    /// Constructor
    /// </summary>
    public Timer()
    {
      startTime = 0;
      stopTime = 0;
      if( !QueryPerformanceFrequency( out freq ) )
      {
        throw new Win32Exception(
          "high-performance counter not supported" );
      }
    }

    /// <summary>
    /// Start the timer
    /// </summary>
    public void Start()
    {
      Thread.Sleep( 0 ); // let waiting threads work
      QueryPerformanceCounter( out startTime );
    }

    /// <summary>
    ///Stop the timer
    /// </summary>
    public void Stop()
    {
      QueryPerformanceCounter( out stopTime );
    }

    /// <summary>
    /// Return the duration of the timer in seconds
    /// </summary>
    public double Duration
    {
      get
      {
        return (double) ( stopTime - startTime )
          / (double) freq;
      }
    }
  }
  #endregion // Timer

Many thanks to Sudhan for implementing this benchmark and reporting these useful (and reassuring) results!

I hope that this encourages you to do some benchmarking as well and helps you optimise your own filtered element collectors.
